6-inch commercial LED downlight with recessed lens for offices and corridors; 120–277V input, 0–10V dimming, 12/16/22/26/30W options (1,440–3,600 lumens) with 2700K/3000K/3500K/4000K/5000K selections.

6″ LED Commercial Downlight 12W/16W/22W/26W/30W 1440–3600 Lumens 2700K/3000K/3500K/4000K/5000K 0–10V Dimming 120–277V

$35.69 $41.99
Skip to product information
6-inch commercial LED downlight with recessed lens for offices and corridors; 120–277V input, 0–10V dimming, 12/16/22/26/30W options (1,440–3,600 lumens) with 2700K/3000K/3500K/4000K/5000K selections.
  • 6-inch commercial LED downlight with recessed lens for offices and corridors; 120–277V input, 0–10V dimming, 12/16/22/26/30W options (1,440–3,600 lumens) with 2700K/3000K/3500K/4000K/5000K selections.
  • 4″ LED commercial downlight side profile showing top conduit feed into the wiring compartment and dual spring clips for recessed ceiling installation; 120–277V input with 0–10V dimming, 6/8/10/12/16W selectable delivering 600–1,515 lumens with 2700K/3000K/3500K/4000K/5000K CCT options.
  • Top view of the 4" commercial LED downlight showing spring-loaded mounting clips on both sides, conduit entry into the top housing, and a close-up of the CCT-select and wattage-select slide switches on the driver box; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • Oblique overhead view of the 4″ commercial LED downlight showing steel spring clips, conduit entry into the dark gray top housing, and blue CCT and wattage selectable slide switches; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • Angled top-down close-up of the 4″ LED commercial downlight showing side conduit entry into the gray top housing, blue selectable wattage/CCT slide switches, and stainless steel mounting clips; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • 6-inch commercial LED downlight with recessed lens for offices and corridors; 120–277V input, 0–10V dimming, 12/16/22/26/30W options (1,440–3,600 lumens) with 2700K/3000K/3500K/4000K/5000K selections.
  • 4″ LED commercial downlight side profile showing top conduit feed into the wiring compartment and dual spring clips for recessed ceiling installation; 120–277V input with 0–10V dimming, 6/8/10/12/16W selectable delivering 600–1,515 lumens with 2700K/3000K/3500K/4000K/5000K CCT options.
  • Top view of the 4" commercial LED downlight showing spring-loaded mounting clips on both sides, conduit entry into the top housing, and a close-up of the CCT-select and wattage-select slide switches on the driver box; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • Oblique overhead view of the 4″ commercial LED downlight showing steel spring clips, conduit entry into the dark gray top housing, and blue CCT and wattage selectable slide switches; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • Angled top-down close-up of the 4″ LED commercial downlight showing side conduit entry into the gray top housing, blue selectable wattage/CCT slide switches, and stainless steel mounting clips; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • 6-inch commercial LED downlight with recessed lens for offices and corridors; 120–277V input, 0–10V dimming, 12/16/22/26/30W options (1,440–3,600 lumens) with 2700K/3000K/3500K/4000K/5000K selections.
  • 4″ LED commercial downlight side profile showing top conduit feed into the wiring compartment and dual spring clips for recessed ceiling installation; 120–277V input with 0–10V dimming, 6/8/10/12/16W selectable delivering 600–1,515 lumens with 2700K/3000K/3500K/4000K/5000K CCT options.
  • Top view of the 4" commercial LED downlight showing spring-loaded mounting clips on both sides, conduit entry into the top housing, and a close-up of the CCT-select and wattage-select slide switches on the driver box; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • Oblique overhead view of the 4″ commercial LED downlight showing steel spring clips, conduit entry into the dark gray top housing, and blue CCT and wattage selectable slide switches; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • Angled top-down close-up of the 4″ LED commercial downlight showing side conduit entry into the gray top housing, blue selectable wattage/CCT slide switches, and stainless steel mounting clips; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • 6-inch commercial LED downlight with recessed lens for offices and corridors; 120–277V input, 0–10V dimming, 12/16/22/26/30W options (1,440–3,600 lumens) with 2700K/3000K/3500K/4000K/5000K selections.
  • 4″ LED commercial downlight side profile showing top conduit feed into the wiring compartment and dual spring clips for recessed ceiling installation; 120–277V input with 0–10V dimming, 6/8/10/12/16W selectable delivering 600–1,515 lumens with 2700K/3000K/3500K/4000K/5000K CCT options.
  • Top view of the 4" commercial LED downlight showing spring-loaded mounting clips on both sides, conduit entry into the top housing, and a close-up of the CCT-select and wattage-select slide switches on the driver box; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • Oblique overhead view of the 4″ commercial LED downlight showing steel spring clips, conduit entry into the dark gray top housing, and blue CCT and wattage selectable slide switches; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
  • Angled top-down close-up of the 4″ LED commercial downlight showing side conduit entry into the gray top housing, blue selectable wattage/CCT slide switches, and stainless steel mounting clips; 6/8/10/12/16W, 600–1,515 lm, 2700K/3000K/3500K/4000K/5000K, 0–10V dimming, 120–277V.
6″ LED Commercial Downlight 12W/16W/22W/26W/30W 1440–3600 Lumens 2700K/3000K/3500K/4000K/5000K 0–10V Dimming 120–277V

6″ LED Commercial Downlight 12W/16W/22W/26W/30W 1440–3600 Lumens 2700K/3000K/3500K/4000K/5000K 0–10V Dimming 120–277V

Brand: NCLTG
SKU: NC-CDL6-30W-5CW
Product Type: LED Recessed Light

Standard recessed applications that require moderate output with field-adjustable performance can specify this 6-inch commercial downlight for adaptable lighting plans. It supports selectable 12W, 16W, 22W, 26W, or 30W operation delivering 1,440 to 3,600 lumens to align with ceiling height and spacing. Five selectable CCT options (2700K through 5000K) support color continuity across the building, and 0–10V dimming with 120–277V input supports integration with commercial lighting control systems.
$35.69 $41.99
Secure Checkout

Payment information is processed through encrypted, PCI-compliant payment gateways. Card details are never stored on our servers.
  • American Express
  • Apple Pay
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa
Shipping information

Shipping is calculated at checkout based on product type, destination, and delivery method (parcel or freight). For lead times, tracking, freight delivery, and inspection requirements, see Shipping Reliability & Fulfillment.
Returns & Restocking

Returns and restocking are handled through an authorization and routing process based on product type and manufacturer policy. Some returns may be subject to a manufacturer-determined restocking fee. For eligibility, steps, and correction handling, see Returns & Restocking.

Specifications

BrandNCLTG
Manufacturer Part NumberNC-CDL6-30W-5CW
Wattage12W, 16W, 22W, 26W, 30W
Voltage120–277V
Lumens1,440, 1,920, 2,640, 3,120, 3,600
Efficacy120 lm/W
CCT2700K, 3000K, 3500K, 4000K, 5000K
Dimming0–10V
Special FeaturesWattage and CCT Selectable
CertificationscETLus Listed, Energy Star Rated
Dimensions8.3"D x 4.8"H
Warranty5-Year Limited Warranty
