Name: 10″ LED Recessed Downlight 18/23/30W 1800–3000 Lumens 3000K/3500K/4000K 120–277V
Brand: SLG Lighting
SKU: DRS-10R-18-23-30-G2-FSK
Price: 59.0 USD
Availability: InStock

10″ LED Recessed Downlight 18/23/30W 1800–3000 Lumens 3000K/3500K/4000K 120–277V

Quick Answer: Specify this selectable 18/23/30W 120–277V commercial downlight. Delivers up to 3,000 lumens.

Key Features:

Large Aperture: 10-inch architectural trim.
High Output: Up to 3,000 lumens.
Baffle Trim: Maximum visual comfort.
Damp Rated: Safe for indoor entryways.

Brand	SLG Lighting
Wattage	Selectable: 18W / 23W / 30W
Voltage	120–277V
Lumens	Selectable: 1,800 / 2,300 / 3,000
Lamp Type	LED
CCT	Selectable: 3000K / 3500K / 4000K
CRI	80+
Dimming	0–10V
Trim	White Flange with Baffle Trim
Certifications	UL Listed, Energy Star Rated
Minimum Operating Temperature	-4°F
Location Rating	Damp Location
Finish	White
Dimensions	11.22" Diameter × 5.05" Height
Warranty	5-Year Warranty

Selection Guidance: Best for high-ceiling lobbies and hospitality entrance areas. The 10-inch aperture provides a large-scale architectural presence, while the baffle trim minimizes the glare common in high-output recessed cans.

Ceiling Integration & Visual Comfort Considerations

$59.00

Free shipping calculated at checkout.

In stock, ready to ship
Backordered, shipping soon

Start here: For the fastest commercial routing, use Request a Project Quote. For the complete intake → documentation → shipping visibility → closeout workflow, see Commercial Project Support.

Submittals: Submittals
Layouts & IES: Photometrics
Closeout package: Closeout Documentation

Call: (800) 357-6860 Email: support@starsandstripeslighting.com

Quick answer: Shipping method, lead time, and tracking visibility vary by product type and carrier (parcel vs. freight/LTL). For commercial receiving requirements, delivery appointments, inspection steps, and documentation, use Shipping Reliability & Fulfillment.

If you’re working against a site schedule, include your ship-to requirements and target date in your quote request: Request a Project Quote.

Quick answer: Returns and restocking are evaluated based on condition, packaging, and manufacturer requirements. Start here for eligibility, restocking expectations, and documentation steps: Returns & Restocking.

Important: Do not ship items back without an approved return request and routing instructions.

Quick answer: Warranty routing depends on product line and the documentation available (order/PO reference, photos, and configuration details). Use Warranty Claims to submit the required information so we can route your claim correctly.

If you’re submitting project closeout records (submittals, IES, warranty docs), see Closeout Documentation.

Quick answer: For common questions about quoting, documentation, shipping visibility, returns, and warranty routing, use our Frequently Asked Questions page.

For a full commercial workflow overview, start here: Commercial Project Support.

Spec-reviewed for commercial installs

Brandon Waldrop

Lead Commercial Lighting Specialist • Spec Verification + Project Documentation

SLG’s 10″ recessed downlight is reviewed for large-aperture architectural presence, field-tunable output (18/23/30W; 1,800–3,000 lumens), and baffle-trim glare control with damp-rated reliability so lobbies and entryways stay bright and comfortable without harsh cutoff glare, mismatched color, or moisture-related interruptions.

Spec review focus:
Verified for architectural scale using a 10-inch large-aperture trim to create a clean, intentional ceiling appearance in commercial interiors; verified for selectable wattage at 18W / 23W / 30W to right-size light levels by ceiling height and room function without swapping fixtures; verified for high-output capability up to 3,000 lumens to support brighter entries, corridors, and public-facing areas; verified for visual comfort using a baffle trim to reduce direct-view brightness and soften glare in common sightlines; verified for damp-location suitability for indoor entryways and conditioned areas where humidity can be present; verified for color flexibility with 3000K / 3500K / 4000K options to match adjacent spaces and finish palettes without mixed-tone ceilings; verified for 120–277V compatibility for standard commercial electrical conditions.

Verified configuration:
For large-aperture downlights, perceived uniformity comes from repeatable settings and aiming: document the final wattage and CCT per zone and keep spacing consistent so you don’t end up with brighter “pools” under a few trims. On baffle trims, confirm the trim sits flush and the module is seated correctly—small gaps or tilt become visible as uneven cutoff lines, especially in lobbies and long corridors.

Team-backed support: Quotes, photometrics, submittals, shipping visibility, and closeout documentation are supported through Commercial Project Support . Call 800-357-6860.

How this spec is verified
