Technical Specifications & Performance Data
| Brand | NCLTG |
|---|---|
| Manufacturer Part Number | NC-WPE-60W-CWP-3CCT |
| DLC Product ID | S-LV6K3H |
| Wattage | 30W, 40W, 50W, 60W |
| Voltage | 120–277V |
| Lumens | 4,770, 6,320, 7,800, 9,471 |
| Efficacy | 139-159 lm/W |
| CCT | 3000K, 4000K, 5000K |
| Dimming | 0–10V |
| Special Features | Wattage and CCT Selectable |
| Certifications | UL Listed, DLC Premium Listed |
| IP Rating | IP65 |
| Minimum Operating Temperature | -22°F |
| Dimensions | 14.2"W x 9.3"H x 7.3"D |
| Warranty | 5-Year Limited Warranty |
Project Documentation & Technical Downloads
Related Lighting Systems & Categories
Commercial Applications & Site Integration
Technical FAQ Deep-Dive
What wattage options are available for the LED Wall Pack Light?
The LED Wall Pack Light is available in four selectable wattage settings: 30W, 40W, 50W, and 60W. This range is suited for perimeter doors, service corridors, and mid-height exterior walls where output needs vary by mounting height and fixture spacing.
What lumen outputs correspond to each wattage setting?
The lumen packages by wattage are: 30W provides 4,770 lumens, 40W provides 6,320 lumens, 50W provides 7,800 lumens, and 60W provides 9,471 lumens. These steps support on-site tuning to meet target illuminance levels without changing the fixture body.
How does 139–159 lm/W efficacy affect connected load and ROI?
An efficacy of 139–159 lm/W lowers connected load for a given light output, which directly improves energy cost performance on long nightly run schedules. For ROI calculations, use the selected wattage as the project watt input, subtract the baseline fixture wattage, multiply the savings by annual operating hours and the blended utility rate, then account for any DLC Premium rebate value and maintenance reductions tied to longer service intervals.
What CCT options are available, and when would each be used?
The selectable CCT options are 3000K, 4000K, and 5000K. 3000K is commonly selected where warmer appearance is preferred, 4000K is a balanced commercial default for general exterior circulation, and 5000K is typically specified where higher perceived brightness and visual contrast are required for security and camera coverage.
Does this fixture support dimming and exterior control integration?
Yes. The wall pack includes 0–10V dimming for scheduled step-down, late-night reduction, and integration with lighting control panels, photocells, and timeclock-based systems that use low-voltage dimming interfaces.
What does an IP65 rating indicate for outdoor durability?
IP65 indicates dust-tight construction and protection against water jets. For performance in the field, ensure the mounting surface is flat and the gasket and conduit entries are sealed so water cannot track into the wiring compartment.
What is the minimum operating temperature, and why does it matter for driver performance?
The minimum operating temperature is -22°F. This supports cold-weather start and stable operation in winter conditions, which is relevant for exterior wall applications exposed to sustained low ambient temperatures.
What certifications are included for documentation and rebate submittals?
This model is UL Listed and DLC Premium Listed. UL listing supports safety compliance documentation, and DLC Premium listing is commonly used for rebate qualification and performance substantiation in retrofit and new construction submittal packages.
What are the fixture dimensions for layout and mounting checks?
The housing measures 14.2" W × 9.3" H × 7.3" D. Confirm clearance to door swings, downspouts, and conduit routing to maintain intended placement and aiming.
What warranty coverage is provided?
The LED Wall Pack Light includes a 5-year limited warranty. Record the commissioned wattage and CCT selections during closeout so future maintenance can match the configured performance.
