LED UFO High Bay Light 150W/200W/240W 22500–36000 Lumens 4000K/5000K/5700K 0–10V Dimming 120–277V

What is the wattage range for the LED UFO High Bay Light?

The LED UFO High Bay Light offers three selectable wattage options: 150W, 200W, and 240W, optimized for use in various commercial environments such as cold storage, distribution centers, and high-ceiling warehouses.

How does the LED UFO High Bay Light’s efficacy compare to industry standards?

The fixture achieves 150 lm/W efficacy, which is crucial for meeting Lighting Power Density (LPD) requirements as per ASHRAE 90.1-2022. This ensures compliance with energy codes while maintaining sufficient illumination for high-bay spaces such as warehousing or manufacturing.

What CCT options are available for the LED UFO High Bay Light?

The fixture offers field-selectable CCTs: 4000K, 5000K, and 5700K. This allows precise tuning for different tasks:

• 4000K: Ideal for high-bay retail environments where visual comfort is key.
• 5000K: The industrial standard for enhancing visual acuity in assembly zones.
• 5700K: Best for high-contrast settings like loading docks where safety and detail recognition are critical.

Can the LED UFO High Bay Light be dimmed?

Yes, the fixture supports 0-10V dimming, enabling integration with modern Building Management Systems (BMS). This dimming feature facilitates compliance with Title 24 and IECC mandates, including Daylight Harvesting and Demand Response (DR) protocols, which help reduce peak grid demand.

What certifications does the LED UFO High Bay Light hold?

This fixture is UL Listed, RoHS Compliant, and DLC Premium certified, ensuring that it meets rigorous safety, environmental, and performance standards. It is also IP65 rated, making it suitable for harsh environments where dust and water exposure are common.

How does the LED UFO High Bay Light contribute to energy savings?

With an efficacy of 150 lm/W, the LED UFO High Bay Light ensures low energy consumption while maintaining high output. The fixture’s compliance with ASHRAE 90.1-2022 LPD limits reduces the total system wattage, lowering peak demand charges for facilities.

What is the lumen output for the different wattages of the LED UFO High Bay Light?

The lumen output varies based on wattage: 150W provides 22,500 lumens, 200W delivers 30,000 lumens, and 240W outputs 36,000 lumens. These options provide flexibility for large open spaces and high-ceiling areas.

What is the expected lifespan of the LED UFO High Bay Light?

The fixture features a L70 rating of 50,000 hours, meaning it will maintain 70% of its initial luminous flux after 50,000 hours of operation. This is achieved through effective heat dissipation via the aluminum alloy housing, ensuring long-term reliability and compliance with IES TM-21 longevity standards.

How does the LED UFO High Bay Light support lifecycle engineering?

The fixture’s 50,000-hour L70 rating confirms that it will retain at least 70% of its light output over its lifespan. Its robust aluminum housing acts as a passive heat sink, preventing premature lumen depreciation, and ensuring that the fixture meets lifecycle requirements set by ASHRAE and IES standards.

How does the 0-10V dimming feature support Building Management Systems (BMS)?

The integrated 0-10V sinking driver allows the fixture to interface with BMS for optimized control. This feature supports energy-saving measures such as Demand Response (DR), where the lighting load can be reduced by up to 20% during peak utility events, aligning with both Title 24 and IECC guidelines.

What is the significance of the DLC Premium certification for this light fixture?

The DLC Premium certification ensures that this LED UFO High Bay Light meets the highest efficacy and lumen maintenance standards, which is essential for qualifying for top-tier utility rebates. This certification also verifies the fixture’s long-term performance and energy savings in demanding industrial applications.

Is the LED UFO High Bay Light suitable for use in outdoor environments?

Yes, the LED UFO High Bay Light is IP65 rated, making it dust-tight and water-resistant, suitable for outdoor and industrial environments where exposure to the elements is a concern.

What warranty coverage does the LED UFO High Bay Light come with?

The LED UFO High Bay Light is backed by a 5-year limited warranty, ensuring dependable performance and support throughout its lifecycle.
