2×2 LED Panel Light Retrofit 15/20/25/30/40W 1950–5000 Lumens 3500K/4000K/5000K/5700K/6500K 0–10V Dimming Integrated Sensor Receptacle 120–277V

Designed for commercial and institutional 2×2 ceiling retrofit projects where existing troffer housings are reused and automated lighting control is required, including offices, classrooms, healthcare facilities, corridors, and administrative spaces focused on energy efficiency and code compliance.

2×2 LED Panel Retrofit Design: Engineered to retrofit existing 2×2 troffer housings, reducing labor time and avoiding full fixture replacement.
Selectable Wattage: Field-adjustable power settings of 15W, 20W, 25W, 30W, or 40W for precise output matching.
Lumen Output: Delivers 1,950, 2,600, 3,250, 3,810, or 5,000 lumens based on selected wattage.
CCT Selectable: Adjustable color temperatures of 3500K, 4000K, 5000K, 5700K, or 6500K to suit visual comfort and task requirements.
Dimming Capability: Compatible with 0–10V dimming systems for smooth light level control during normal operation.
Integrated Sensor Receptacle: Factory-installed sensor port supports occupancy or daylight sensors for automated lighting control and energy savings.
Input Voltage: Operates on 120–277V commercial electrical systems.
Luminous Efficacy: Rated at approximately 125–130 lumens per watt depending on configuration.
Optical Performance: Panel optics provide uniform illumination with reduced glare when installed in existing housings.
Certifications: cETLus listed, RoHS compliant, and DLC Premium listed for energy code compliance and utility rebate eligibility.
Service Life: Designed for up to 50,000 hours of operation to minimize maintenance cycles and total cost of ownership.

$54.99 $46.74 Save $8.25

Free shipping calculated at checkout.

In stock, ready to ship
Backordered, shipping soon

Brand	NCLTG
Manufacturer Part Number	NC-BPLK22-M40W-CCT-S
DLC Product ID	S-JFV025
Wattage	15W, 20W, 25W, 30W, 40W
Voltage	120–277V
Lumens	1,950, 2,600, 3,250, 3,810, 5,000
Efficacy	125–130 lm/W
CCT	3500K, 4000K, 5000K, 5700K, 6500K
Dimming	0–10V
Special Features	Wattage and CCT Selectable, Integrated Sensor Receptacle
Certifications	cETLus Listed, RoHS Compliant, DLC Premium Listed
Dimensions	21.41"L x 22.08"W x 1.47"H
Warranty	5-Year Limited Warranty
